Dual Battery Isolator Kit 140A

If you are the DIY type, then this is the kit for you. It is an easy to install kit, which should only take 2-3 hours to install on the average 4x4. This kit utilises a 140A rated VSR type isolator which will automatically isolate your deep cycle/second battery from the vehicles main start battery, meaning a correctly set up system will not draw down on the starting battery. Charging is prioritised to the start battery, once the start battery is up to correct voltage the system then connects to the deep cycle battery.

• Kit is designed for 12VDC.
• Max current rating of the Voltage Sensitive Relay (VSR) is 140A.
• VSR connects (starts charging) at 13.3Volts.
• VSR disconnects at 12.8Volts.
• VSR has an IP65 rating.

The Dual Battery Isolator Kit 140A contains the following components:

• VSR Smart Isolator rated up to 140A
• 6 metres of 8AWG Red Cable which is terminated at both ends
• 0.6 metre of 8AWG Black Cable terminated at both ends
• 2x Positive Marine Type Battery Terminals
• 1x Negative Marine Type Terminal
• 3x CAL16-8 Cable Lugs
• 2 pieces of Red Heat Shrink
• 1 piece of black Heat Shrink
• 1x Blue Ring Terminal
• 6x 300mm Cable Tie
• 4x Self Tapping Screws
• 2x M6 Nuts
• 2x M6 Spring Washers
